Thermal Monocular Pulsar Telos Lrf Xp50

Name: THERMAL MONOCULAR PULSAR TELOS LRF XP50
Brand: Pulsar
SKU: 288645

Read more-Product description

£2829.40

Recommended retail price : £2829.40

20 days for returns

Models & specificities

Descriptive

Models & specificities Descriptive

Models & specificities

Back to menu

Reference

Price inc VAT

77492

£2829.40

Models & specificities Descriptive

Descriptive

Back to menu

The components and software solutions of high-tech industries improve every year. Thermal imaging is no exception. Over time, users' choices and preferences change. Moreover, with experience, users evolve their requirements regarding the device's capabilities and operation. The Telos thermal imaging monocular was designed taking into account the available technology and the users' needs. Telos is the first range of thermal vision devices on the market offering technical upgrades on the customer's demand. Acquire a Telos and discover how to upgrade it flexibly and cost-effectively for the years to come. Equip it with a powerful optic, a sensor and a higher-resolution display, with more efficient and functional electronics, or fit it with a laser rangefinder and additional optical channels so you always have the latest device, but at the simple price of upgrades.

• Sensor: 640x480 pix. @ 17 µm (NETD <18 mK)
• Lens: F50 / 1.0
• Zoom, x: 2.5 – 10 (x4 digital zoom)
• Zoom in monocular mode / attachment mode, x: -
• Field of view (HxV), degrees / m at 100 m: 12.4x9.3 / 21.8x16.3
• Detection range, m: 1800

- Sensor
• Type: uncooled
• Resolution, pixels: 640x480
• Pixel pitch, µm: 17
• NETD, mK: <18
• Frame rate, Hz: 50

- Optics
• Lens: F50 / 1.0
• Zoom, x: 2.5 – 10 (x4 digital zoom)
• Zoom in monocular mode / attachment mode, x: -
• Field of view (HxV), degrees / m at 100 m: 12.4x9.3 / 21.8x16.3
• Eye relief, mm: 14
• Recommended day view zoom, x: -

- Display
• Type: AMOLED HD
• Resolution, pixels: 1024x768
• Range performance
• Detection range, m: 1800

- Laser rangefinder
• Laser equipment safety class according to IEC 60825-1: 2014: 1
• Wavelength, nm: 905
• Max. measuring range, m: 1000
• Measurement accuracy, m: ± 1

- Video recorder
• Video / photo resolution, pixels: 1024x768
• Video / photo format: .mp4 / .jpg
• Internal memory, GB: 64
• Internal memory capacity -

- Wifi
• Wireless Protocol: Wi-Fi
• Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency, GHz: 2.4 / 5

- Environmental characteristics
• Degree of protection, IP code (IEC60529): IPХ7 (waterproof)
• Operating temperature range, °С: -25 – +40

- Connections and compatibilities
• Mount, type: 1/4"
• Remote control: -
• Supported application: Stream Vision 2

- Power source
• Output voltage, V: 3.0 – 4.2
• Battery type: LPS 7i Li-Ion Battery Pack
• Capacity, mAh: 6400
• Battery operating time (at t = 22 ° C), h *: 8.5
• External power supply, V: 5V, 9V (USB Type-C Power Delivery)

- Weight and size
• Body material: rubber armored reinforced plastic
• Dimensions, mm: 238x72x90
• Weight, kg: 0.58 (w/o battery) / 0.72 (with the LPS7i battery)
